I like small projects that give an instant payoff. A spiral is perfect for that: a handful of lines, a press of Run in python, and you get clean geometric art you can tweak for hours. Below I walk through my original snippet, rebuild it into a handy draw_spiral()
function, and show a few tricks I use when I want the pattern to feel fresh.
My Code
numpy as np
import matplotlib.pyplot as plt
# --- generate an Archimedean spiral ---------------------------------
theta = np.linspace(0, 12 * np.pi, 2000) # angle values
a = 0.15 # tightness factor
r = a * theta # radius grows linearly
x = r * np.cos(theta)
y = r * np.sin(theta)
# --- plot ------------------------------------------------------------
plt.figure(figsize=(6, 6))
plt.plot(x, y, linewidth=2)
plt.axis("off")
plt.show()
How The Original Snippet Work
Line | What it does | Why it matters to me |
---|---|---|
import numpy as np | Pulls in NumPy. | I need a fast way to create thousands of angle values. |
import matplotlib.pyplot as plt | Loads Matplotlib. | This is my drawing pen. |
theta = np.linspace(0, 12 * np.pi, 2000) | Makes 2 000 evenly spaced angles from 0 to 12π (≈ 6 turns). | More points = smoother curve. |
a = 0.15 | Sets how far each loop sits from the last. | Smaller a = tight coil, bigger a = wide arms. |
r = a * theta | Finds a radius for every angle. | Linear growth = Archimedean spiral (good for even spacing). |
x = r * np.cos(theta) y = r * np.sin(theta) | Converts polar to (x, y) pairs. | Matplotlib speaks Cartesian. |
plt.figure(figsize=(6, 6)) | Opens a 6-inch square canvas. | A square keeps the shape centered. |
plt.plot(x, y, linewidth=2) | Draws one continuous line. | A width of 2 is easy on the eyes. |
plt.axis("off") | Hides ticks and labels. | I want art, not axes. |
plt.show() | Pops the figure on screen. | Without this, nothing appears in many IDEs. |
Explain Code
I often want quick variations different colours, rotated copies, maybe a filled version without rewriting those ten lines each time. So I wrapped the logic in a function:
numpy as np
import matplotlib.pyplot as plt
def draw_spiral(a=0.15, # tightness
turns=6, # full rotations (6 = 12π radians)
linewidth=2,
color='tab:orange',
offset_deg=0, # rotate the whole thing
fill=False,
save_path=None,
show=True):
"""Draw an Archimedean spiral with a few knobs."""
# build the angle array
theta_max = turns * 2 * np.pi
theta = np.linspace(0, theta_max, int(theta_max * 160)) # ~160 pts / rad
r = a * theta
# optional rotation
theta_shifted = theta + np.deg2rad(offset_deg)
# polar → Cartesian
x = r * np.cos(theta_shifted)
y = r * np.sin(theta_shifted)
# plot
fig, ax = plt.subplots(figsize=(6, 6))
ax.plot(x, y, lw=linewidth, color=color)
if fill:
ax.fill(x, y, color=color, alpha=0.15)
ax.set_aspect('equal')
ax.axis('off')
if save_path:
fig.savefig(save_path, dpi=300, bbox_inches='tight', transparent=True)
if show:
plt.show()
return fig, ax
Experiments I Run all The Time
# A super-tight, long swirl
draw_spiral(a=0.05, turns=15, linewidth=1.2, color='purple')
# Two offset spirals for a nautilus look
draw_spiral(a=0.12, turns=8, color='skyblue', fill=True, show=False)
draw_spiral(a=0.12, turns=8, offset_deg=180, color='salmon', fill=True)
# Save a crisp SVG for Illustrator
draw_spiral(a=0.18, turns=5, linewidth=4,
color='black', save_path='spiral.svg')
Hands on Extra When I Want to Play
- Interactive sliders
ipywidgets import interact
interact(draw_spiral,
a=(0.01, 0.5, 0.01),
turns=(1, 20, 1),
linewidth=(0.5, 10, 0.5),
offset_deg=(0, 360, 5),
fill=False,
show=True);
Move the knobs in a Jupyter notebook to see changes live.
- Colour gradients
Maptheta
to a colormap and pass aLineCollection
to Matplotlib for a smooth fade from centre to edge. - Simple animation
Withmatplotlib.animation.FuncAnimation
, increasetheta_max
frame by frame—export as a looping GIF. - Try other spirals
Logarithmicr = b * np.exp(c θ)
or Fermatr = k √θ
for very different vibes. - Add jitter
x += np.random.normal(scale=0.02, size=x.size)
gives an ink-on-paper feel. - Tile for wallpaper
Loop over offsets and colours in a grid ofsubplots
—psychedelic in seconds.
Final Thought
A spiral may look like pure maths, but to me it’s a playground. Each parameter is a knob I can spin for instant feedback: tighter, looser, lighter, louder. The code above started as ten quick lines; now it’s a mini tool I reach for whenever I need background art, a logo seed, or just a quiet break from “serious” work.
